- Model identifier
- PUR 98 D
- Manufacturer material number
- 12050650
- EAN number
- 4002516585794
- Type of air guide
- Can be retrofitted
- Energy efficiency class (A+++ to D)
- A
- Annual energy consumption in kWh/year
- 51.8
- Fluid dynamic efficiency class
- A
- Lighting efficiency class
- A
- Grease filtering efficiency class
- A
- Number x W
- 4 x 3 W
- Light intensity in Lx
- 500 lx
- Colour temperature in K
- 3000 Kelvin
- Air throughput in Level 1 (m³/h) according to EN 61591
- 280
- Air throughput in Level 2 (m³/h) according to EN 61591
- 330
- Air throughput in Level 3 (m³/h) according to EN 61591
- 400
- Air throughput in Booster level 1 (m³/h) according to EN 61591
- 650
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
- 48
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
- 53
- Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3
- 57
- Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3
- 69
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
- 31
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
- 35
- Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
- 39
- Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13
- 51
- Air throughput in Level 1 (m³/h) according to EN 61591
- 190
- Air throughput in Level 2 (m³/h) according to EN 61591
- 270
- Air throughput in Level 3 (m³/h) according to EN 61591
- 330
- Air throughput in Booster level 1 (m³/h) according to EN 61591
- 460
- Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3
- 57
- Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3
- 62
- Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3
- 66
- Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3
- 73
- Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13
- 40
- Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13
- 45
- Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13
- 49
- Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13
- 56
- Canopy dimensions (W x H x D) in mm
- 898 x 70 x 598
- Overall hood height for extraction mode and external in mm
- 690–990
- Overall height for recirculation mode cooker hoods in mm
- 750–1060
- Overall height for vented and external in in. (mm)
- 690
- Overall height for extraction mode and external mode cooker hoods in mm
- 990
- Overall height for recirculation in in. (mm)
- 750
- Overall height for recirculation mode cooker hoods in mm
- 1060
- Canopy width in in. (mm)
- 898
- Canopy height in in. (mm)
- 70
- Depth of hood canopy in in. (mm)
- 598
- Minimum height above electric hobs in mm
- 450
- Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm
- 650
- Net weight in kg
- 34
- Total rated load in kW
- 0.232
- Voltage in V
- 230
- Fuse rating in A
- 10
- Frequency in Hz
- 50
- Number of phases
- 1
- Extraction ducting connection at top
- Diameter of extraction ducting connection in mm
- 150
Easy to use and effective against grease
