W1 front-loader washing machine:PLATINUM

WWG660 WCS TDos&9kg

A I 9 kg I 1400 rpm I Automatic dispensing I Pre-ironing I Miele@home
sale priceAED8,200
All product prices incl. VAT at 5%.


Product details

  • Tested for
    20 years
    of perfect laundry care2,
  • Save energy in the best energy efficiency class (A)
  • Precise and automatic detergent dispensing with
    TwinDos®
    6,
  • The
    Pre-ironing
    Extra reduces creasing, saving up to 50 % time and effort8,
  • Complete app control of your washing machine with
    Miele@home
    3,
  • View manufacturer details:
  • You will find more information about product data and your rights under the EU Data Acthere
  • Safety Information

Product data sheet

Model identifier WWG660 WCS TDos&9kg
Manufacturer material number 11458470
EAN number 4002516303039
Marketing class
Platinum
Suitable for stacking
Side-by-side
Slot-in
Door hinge right
Product brand W1 White Edition
Front-loader
Max. spin speed 1400
Rinse hold
Without spin function
Appliance colour Lotus white
Control panel colour Lotus white
Door design Obsidian black with chrome ring
Rotary selector colour Lotus White / Chrome ring
Control panel version 5° inclined
Control type Rotary control
Display ComfortSensor white, 1 line
TwinDos automatic detergent dispensing
CapDosing portioned dispensing
Honeycomb drum
Load in kg 9
Networking with Miele@home
Delay start up to 24 hours
Time left display
Programme sequence indicator
MultiLingua
AutoClean detergent drawer
AddLoad
Low temperature wash "Cold" and "20 °C"
Automatic load control
Flow meter
Foam sensing
ProfiEco motor
Automatic plus
Cottons (coloureds)
Minimum iron
Delicates
Shirts
Silk (hand-washable)
Woollens (hand-washable)
Express 20
Dark garments / Denim
Outerwear
Proofing
Sportswear
Clean machine
Cottons arrow
Separate rinse/Starch
Drain / Spin
ECO 40-60
Short
Soak
Pre-wash
Water plus
Additional rinse cycle
Extra quiet
Pre-ironing with steam
Buzzer
AllergoWash
Water protection system Watercontrol-System
Safety lock
PIN-Code
Optical interface
Dimensions in mm (width) 596
Dimensions (H x W x D) in mm 850 x 596 x 643
Dimensions in mm (height) 850
Dimensions in mm (depth) 643
Appliance depth in mm with opened door 1077
Weight in kg 94
Total rated load in kW 2.100-2.400
Voltage in V 220-240
Fuse rating in A 13
Frequency in Hz 50
Length of water inlet hose in m 1.60
Length of water drain hose in m 1.50
Length of supply lead in m 2
3 Caps
UltraPhase 1 + 2
Voucher for 5 Miele UltraPhase cartridges
Available display languages via MultiLingua [ "한국어", "español", "english (AU)", "bahasa malaysia", "中文", "日本語", "deutsch", "繁體中文", "english (GB)", "português" ]
EAN 4002516303039

What's included

3 Caps
UltraPhase 1 + 2
Voucher for 5 Miele UltraPhase cartridges

Safety

Safety thanks to an additional sensor
Water Control System (WCS)

WCS monitors the water intake, detects leakages and water in the floor tray.

Quality

Tested for 20 years of perfect laundry care2,
Tested for the equivalent of 20 years’ use2,

Some car engines are subjected to 3000 hours of tests, but we test continuous performance for up to 10,000 hours.2,

User convenience

Smart networking
Miele@home3,

Connect your washing machine to your home network and control it conveniently and intuitively via the app.


Add or remove single items
AddLoad

Enjoy the flexibility to add or remove individual items during a washing cycle, without cancelling the programme.

Efficiency

Tailored to your load
Automatic load recognition

Use precisely the water and energy needed for your laundry with automatic load recognition.


Economical, powerful and maintenance-free
ProfiEco motor4,

Our efficient motors with inverter drive feature technology that ensures minimal wear, noise, and energy usage.

Cleaning performance

Best liquid detergent system with push of a button
TwinDos®automatic detergent dispensing6,

Dispensing the right amount at key moments throughout a wash programme saves you up to 30 %5, detergent.


Always the right detergent for every application
CapDosing portioned dispensing7,

Our portioned caps are available with a range of specialised detergents tailored to match your wash programmes.

Washing programs

Wash and dry two types of textiles
Automatic plus

For mixed loads: cottons and polycottons can be conveniently processed together.


Optimum care of synthetic fibres
Delicates

Gentle & soft: with the special programme synthetic textiles stay beautiful & keep their shape.


Most gentle treatment of your favourite garments
Woollens

No shrinkage, no felting: Delicate wool fabrics are cared for particularly gently, maintaining their quality.


Very delicate handling of natural fibres
Silks

Excellent care: all hand-washable textiles which do not contain wool are washed extremely gently.


Business as usual
Shirts

Prevents creasing: reduces creasing and simplifies the ironing of shirts and blouses significantly.


Special programme for functional clothing
Sportswear

The fitness programme: sportswear is ready to wear again in no time.


Special programme for high-tech materials
Outerwear

Best care without the loss of function: High-quality outdoor textiles retain their functionality in any weather.


Equip textiles with functions
Proofing

Best possible effect: Thermally fixing ensures optimum water-repellent properties.

Gentle laundry care

Keep your clothing safe while tumbling
Honeycomb drum

Our protective drum allows fabrics to safely glide along without snagging and damaging them.


Up to 50 % less ironing
Pre-ironing with steam8,

A specialised steaming feature that reduces wrinkles, saving you substantial effort and time ironing your clothes.

Downloads

Product Fact Sheet
PDF
Downloads
User manual
PDF
Downloads
dwg
ZIP
Downloads
fbx
ZIP
Downloads
ifc
ZIP
Downloads
rfa
ZIP
Downloads
rvt
ZIP
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000018/200001844/20000184418.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
Installation drawings
POSTSCRIPT
Downloads
https://media.miele.com/images/2000018/200001844/20000184419.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
Installation drawings
POSTSCRIPT
Downloads
https://media.miele.com/images/2000018/200001844/20000184420.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
Installation drawings
POSTSCRIPT
Downloads
https://media.miele.com/images/2000018/200001844/20000184421.png
Descriptions
W1 drawing, facia 5 degree, measures in mm
Installation drawings
POSTSCRIPT
Downloads
  • 1.All product prices incl. VAT at 5%.
  • 2.During the development phase of the W1 / W2 washing machine series, Miele tested models and core components in 5000 wash loads (= 5 wash loads per week for 50 weeks per year) in various programmes. More: miele.com/20years
  • 3.This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.
  • 4.Patent EP 2 840 679
  • 5.According to Öko-Institut e.V. report dated 06.09.2013: “Potential savings with automatic TwinDos ® dispensing on washing machines”.
  • 6.Patent EP 2 784 205
  • 7.Patent EP 2 365 120
  • 8.Patent EP 2 088 231

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
